High Quality Semi-Automatic Bottle Blowing Machine

Basic Info

Product Description

Semi-automatic  bottle blowing machine

King Machine series are the most stable two-step fully-automatic pet stretch-blow moulding machines(reheat). It has one to six cavities and the maximum capacity of the products is 2L. It can blow bottles in shapes: Carbonated, mineral, pesticide, cosmetics, wide-mouth, hot filling, and other packing containers, which is made of plastic of crystalline type, such as PET and PP etc.

Model	BLS-2000HF,BLS-4000HF,BL-6000HF
Number of Cavities	2 Cavity,4 Cavity,6Cavity
Theoretical Output	2500BPH,4000BPH,6000BPH
Voltage Standard	380v/3PH/50Hz or special order
Total Power	48KW
Max.Container Volume	1.5L
Neck Diameter Range	20-50mm
Max.Container Height	320mm
Size	3.21.61.8m,41.61.8M,52.51.8M
Net Weight	2T,4T,6T

 Hot sell !!!!!seim automatic PET bottle blowing machine (for heat resistent bottle ) ---Air Comperssor:



Features of  Hot sell !!!!!seim automatic PET bottle blowing machine (for heat resistent bottle ) :
1. Stable performance with advanced PLC.
2. Conveying preforms automatically with conveyor.
3. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.
4. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.
5. High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.
6. No contamination and low noise with the air cylinder to drive the action instead of the oil pump.
7. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
8. Strong clamping force with high pressure and double crank links to lock the mold.
9. Two ways of operating: Automatic and manual.
10. Safe, reliable, and unique design of the position of valve to make the air pressure diagram of the machine easier to understand.
11. Low cost, high efficiency, easy operation, easy maintenance, etc, with automatic technological process.
12. Contamination is avoided for the bottle body.
13. Ideal effect of the chilling with the chilling system.
14. Easy installation and starting
15. Low rejection rate: Less than 0.2 percent.
